Prefeeding & Collector
Prefeeding & Collector is a device used to support and release wire during cable and wire processing. It uses a rotating or fixed structure to ensure that the wire is unwound in an orderly manner, thereby reducing tangling and damage to the wire.
Home Porducts Prefeeding & Collector
Products
Our products have passed 3C certification, with reliable quality and durability.
Products Category
< >
Full Automatic Cable Feeding Machine
Model:MN-F7005-1
ENQUIRE NOW!
Automatic Wire Feeding Machine with adjustable feature, putting auto-sensing line to ensure the line is automatically sent based on the length of the cut line, This machine makes wires no tie, no twisting, ensure the wires feeding into machine to be straight, It can be used with:
Specifications
Feature
Download
NameSingle wire type double motor pay-off machine
ModelMN-P7005
Powersupply220v50hz
Power120w/180W
Size500*800*900mm
Clamping wire disc outerdiameter400mm
Spool outerdiameter25mm
Number ofspoolsone
Pay-offspeed1meter/second
Single axisbearingweight25kg
Speed regulationmodeManual speedregulation
BrakeElectronic inductionbrake
Weight90kg
ApplicationActive pay-off


Automatic Wire Feeding Machine with adjustable feature, putting auto-sensing line to ensure the line is automatically sent based on the length of the cut line, This machine makes wires no tie, no twisting, ensure the wires feeding into machine to be straight, It can be used with:
1. Automatic terminal crimping machine.
2.Automatic wire stripping cutting machine.
3.Wire cutting machine.
4.Automatic wire stripping machine.
