| Model | MN-C02 Electric Cut to Length Machine |
| Cutting blade | Cold |
| Raw material | Fiber, PVC, Teflon, Low halogen, Fiberglass, etc |
| Cutting width | 100 mm [ 200 / 300 / 420 / 550 / 650 / 1000 mm are available ] |
| Cutting length ( L ) | 0.1 - 5000 mm [ 50000 mm on request ] |
| Productivity | 80 - 120 pcs/min |
| Power supply | AC 110 - 220V + 10 %, 50 / 60 Hz |
| Dimensions | L 410 x W 350 x H 300 mm |
| Weight | 22 KG |
Versatile electrically driven cutting machine
Velcro (hook & loop) tape
Heat shrinkable tubing
Fast, precise, quiet
User-friendly interface
No need training
Cold cutting machine
The MN-C02 cutting machine is a perfect solution in the wire harness industry as well as the textile industry, it can process various materials, including hook & loop tape, plastic tubing, films, bootlaces, plastic zippers, labels, hoses.
The MN-C02 cut to length machine uses rubber and metal rollers together to feed the material, this protects the material as well as offers precise feeding length. This cutting machine offers precise digital control of cut to length and quantity, It#39;s ideal to increase efficiency, improve quality, and save on labor costs.
We also supply the cutting machine with a hot cutter blade, and various cutting shapes can be customized to meet customers#39; requirements. Just contact us, we will offer a full range of cutting solutions.
