| Conductor cross section | 0.5-16mm² |
| Cutting length | 0.01-99999.9 mm |
| Cutting length increment | 0.01 mm |
| Cutting length tolerance | <0.002*L(L=cuting length) |
| Full stripping length (left side) | 0.01-100 mm |
| Full stripping length (right side) | 0.01-70 mm |
| Stripping length increment | 0.01mm |
| Guide tube diameter | 4/6/8/10 mm |
| Detection | No wire detection |
| Guide tube jump | Powered by air cylinder |
| Transmission structure | Twin lead screws+hybrid servo motor |
| Feeding speed | 0.67-0.83 ms |
| Feeding mode | 12-roller plus belts feeding |
| Productivity | 1500-2500 pcs.h |
| Blade material | High speed steel/tungsten steel (optional) |
| Display mode | 7"touchscreen |
| Program storage capacity | 100 programs (quick copy) |
| Useful function | Automatic feeding,activation by alarm,jog mode for operating manuall |
| Pover | 1.4kW |
| Rated power | 0.8KW |
| Powver supply | 220/110V(50/60 Hz) |
| Power cord type | Diferen types for diferent standards |
| Compressed air connection | 0.5-0.8MPa |
| Weight | 65kg |
| Dimension | 650×570×455mm |
Quick belt replacement: The belt features a snap-on mounting mechanism, eliminating the need to disassemble the feeder assembly. A single operator can complete belt replacement in 5-8 minutes, significantly faster than the 20-30 minutes required for traditional wire strippers. The belt is oil- and wear-resistant, boasting a lifespan of 6,000-10,000 hours under normal use—1.5-2 times that of traditional metal feeders—reducing the frequency of replacement of wearing parts.
No risk of oil contamination: The belt drive eliminates the need for frequent lubrication, preventing lubricant from penetrating the wire insulation or core (especially suitable for clean wire processing in the electronics industry). This reduces internal oil cleaning and saves approximately 20% of maintenance hours annually.
