Fully automatic wire stripping machine is an industrial device that uses cutting tools or other means to achieve precise stripping of the insulation layer of wires/cables without damaging the insulation. It is widely used in fields such as electronics manufacturing, automotive, communications, and new energy. It supports various types of wires, including single-core wires, multi-core wires, coaxial wires, shielded wires, and more.

Products

Our products have passed 3C certification, with reliable quality and durability.

Products Category

Products Category

< >

Wire Cutting & Stripping Machine (OD 2-35mm)
Model:MN-S360

ENQUIRE NOW!

Model number: MN-S360
Wire Outer Diameter: 2-16mm
Wire Size: 2-35mm²
Diameter of conduit: 10-12-14-16-18-20
Stripping length: 0.1-200mm，0.1-70mm

Specifications

Feature

Download

The name of the device	Automatic computerized wire stripping machine
Cut the core	2-35 sq.m
Device model	MN-S360
Cutting wire diameter	2-16mm
The weight of the whole machine	75kg
Catheter diameter	4-6-8-10-12-14-16
Dimensions	L650mmW570mmH455mm
Detection function	Missing line detection
Enter the power supply	AC220V/50Hz
Catheter swinging	Pneumatic
The power of the whole machine	18KW
Tangent length	0.01-999999.99mm
Rated power	0.8KW
Stripping length	0.01-200mm
How it is displayed	7-inch touchscreen display
Stripping length	0.01-70mm
Control system	6-axis motion control board
Bi-directional	Pressure regulation (computer-adjusted pressure)
Device features	Wire cutting and stripping at both ends
Tungsten Blade material	steel/Swedish high
Wire feeding method	12-wheel crawler feed
speed steel Operating air	0.5-0.8MPa
Feed speed	40-50 m/min
pressure Capacity/hour	1000-1500 pcs/hour
Transmission structure	Servo motors, hybrid stepper motors, precision two-way screws, linear guide pillars
Program storage	No.0-99(one-build copy, one-click reading, customizable number name)

Quick belt replacement: The belt features a snap-on mounting mechanism, eliminating the need to disassemble the feeder assembly. A single operator can complete belt replacement in 5-8 minutes, significantly faster than the 20-30 minutes required for traditional wire strippers. The belt is oil- and wear-resistant, boasting a lifespan of 6,000-10,000 hours under normal use—1.5-2 times that of traditional metal feeders—reducing the frequency of replacement of wearing parts.

No risk of oil contamination: The belt drive eliminates the need for frequent lubrication, preventing lubricant from penetrating the wire insulation or core (especially suitable for clean wire processing in the electronics industry). This reduces internal oil cleaning and saves approximately 20% of maintenance hours annually.
