| Model | MN-X4520S |
| Wire diameter | 6-43mm |
| Stripping length | 0-200mm |
| Stripping mode | Rotary stripping |
| Length accuracy | ±(0.002*L)mm |
| Max.stripping layer | 9 layers |
| Memory program | 99 |
| Drive mode | Motor\ballscrew drive |
| Display | Touch Screen |
| Blades | Imported tungsten steel |
| Power | 2000W |
| Cut precision | 0.01mm |
| Dimension | 1150*430*1350 |
| Power supply | AC220V/50Hz(110V is optional) |
| Weight | 215KGS |
1.HMI(human machine interface) control, easy to understand operation, can peel up to 9 layers, can store up to 99 groups of processing data.
2.Rotation blade head, four piece rotation blade design and exquisite structure improve the stability of wire stripping and the working life of the tool.
3.Adopt servo motor, precision ball screw and multi-point motion control system, stable and efficient performance.
4.The cutting tool adopts imported tungsten steel and titanium alloy coating, sharp and durable.
5.It can meet the special requirements of multi-layer peeling, multi-section peeling, automatic continuous starting, etc.
